美國MiTeGen由康奈爾大學教授Robert Thorne于2004年創(chuàng)立，專注于開發(fā)和生產用于蛋白質、病毒和小分子/無機化合物的冷凍電鏡（冷凍電子顯微鏡）、結晶、晶體學和 X衍射產品。

Dual Thickness MicroLoops LD

貨號：M5-L18SP-XXLD

Great for sub-microliter drops and microfluidic crystallization cards/chips.

Puncture protein skins and retrieve crystals without removing the skin.

Thick polymer in the neck region makes these loops very rigid in liquid drops and cold gas streams. Thin polymer in the loop region ensures the lowest possible background scatter in X-ray diffraction applications.

Dual-Thickness MicroLoops LD? have aperture sizes of 20, 35, 50, 75, 100, 150, 200, and 300 μm.

These are available in single size boxes of 20 pins and 2 different assortments:

• A1: 20 pins, 5 each of 20, 35, 50, and 75 μm.

• A2: 20 pins, 5 each of 100, 150, 200, and 300 μm.

MicroLoops LD? are built on 18 mm / SPINE length rods (pins), which are now standard at nearly all synchrotron beam lines in the world. Other pin lengths are also available: (11mm, 19mm, and 25mm)

We strongly recommend using heavy-duty, serrated-tip tweezers to handle MicroLoops LD?.

MicroLoops LD? are compatible with all standard X-ray hardware and can be inserted in 0.7 mm mechanical pencils or micromanipulators for easy handling.

希凱生物是MiTeGen授權代理商，負責其中國區(qū)的銷售與技術服務

更多產品信息，歡迎直接與我們聯(lián)系
